JA Solar JAM72S30GR 540-565W

JA Solar JAM72S30GR 540-565W

570W 575W 580W 585W 590W 595W JA Deepblue 3.0 Series Half Cell Module. Assembled with 11BB PERC cells and gapless ribbon connection technology, the modules can offer higher output power with improved module efficiency, the reduction of cells gaps brings outstanding module appearance. The half-cell configurature makes less shading effect, lower risk of hot spot, as well as more reliable and stable power generation.
18168927132@honghongah.cn
86 18168927132

Product Details


MECHANICAL DATA
CellMono
Weight27.3kg
Dimensions2278±2mm*1134±2mm*30±1mm
Cable Cross Section Size4mm²(IEC)，12 AWG(UL)
No. of cells144(6*24)
J-BoxIP68, 3 diodes
ConnectorQC 4.10-351/ MC4-EVO2A


ELECTRICAL DATA(STC)
Rated Maximum Power(Pmax)[W]540545550555560565
Power Tolerance0~+5W
Open Circuit Voltage(Voc) [V]49.649.7549.950.0250.1550.28
Maximum Power Voltage(Vmp) [V]41.6441.841.9642.1142.2742.42
Short Circuit Current(lsc) [A]13.8613.931414.0714.1414.21
Maximum Power Current(lmp) [A]12.9713.0413.1113.1813.2513.32
Module Efficiency[%]20.90%21.10%21.30%21.50%21.70%21.90%




Product Application

Efficient solution for large-scale ground power stations

Double sided double glass 700W+high-power component
Double sided power generation gain of 30%+(in sandy/grassland scenarios)
1500V system voltage reduces BOS costs by 8%~12%
Adapt to tracking bracket, increase annual power generation by 18% to 25%

Industrial and commercial roofs

Lightweight design ≤ 9kg/m ² (traditional components 15kg/m ²)
Flat roof with a 5 ° inclination angle for non-destructive power generation
Wind pressure resistance capacity ≥ 5400Pa (verified in typhoon areas)
Quickly install the system, increase construction efficiency by 40%

Household photovoltaic system

Integrated design of micro inverter
Shadow occlusion loss<5% (traditional string style 15%+)
Intelligent APP real-time monitoring, fault location accuracy of 99%
IP68 protection level, suitable for various roof environments

Extreme environment customization

-Starting efficiency at 40 ℃ environment ≥ 94%
Salt spray corrosion resistance certification (IEC 61701 Class IV)
Annual attenuation rate of 0.5% in desert environment
Snow reflection gain power generation+22%
